SU 180 mm Stainless Steel Conveyor

Contact Us
Conveyor specialists are ready to help you find the right solution

Benefits of SU 180 mm Stainless Steel Conveyors:

The SU Conveyor is suitable for a wide range of applications either for horizontal or vertical product transportation.

Different Conveyor Chain Types
The SU multi-flexing conveyor systems uses a plastic chain that permits horizontal as well as vertical change of direction. In addition to the standard types, several special purpose chains are available. Take a look in the Tech Data located under Manuals & Literature for all options available. Please contact us or your local distributor for further assistance.

Chain Width (mm)

Conveyor Chain Width (mm)
 Chain Width (mm) 175
 Tensile strength at 20ºC (N) 4800
 Max. working tensile at 20ºC (N) 1250
 Working temperature ºC -20 to 60
 Link spacing (mm) 33.5
 Min. turning radius (mm) 500
 Max. conveyor length (m) 30
 Standard conveyor speed (m/min) 58
 Item width (mm) 50 to 400
 Max. weight on conveyor (kg/m) 65
 Chain weight (plain) (kg/m) 2

Chain Width (inch)

Conveyor Chain Width (inch)
 Chain Width (inch) 6.89
 Tensile strength at 68ºF (lbf) 1079
 Working temperature ºF 281
 Min. turning radius (inch) -4 to 140
 Max. working tensile at 68ºC (lbf) 1.32
 Link spacing (inch) 19.7
 Max. weight on conveyor (lb) 100
 Item width (inch) 190
 Max. conveyor length (ft) 2 to 15.4
 Standard conveyor speed (ft/min) 44
 Chain weight (plain) (lb/ft) 1.34
